1600Tons Short Cycle Lamination Hot Press Machine

产品详情

General Instruction for the Shor Cycle Lamination Hot Press Machine： 1.1 Pressing Thickness Range:8mm—45mm 1.2 Capacity:about 70 sheets/hour 1.3 Infeed Method:Belt Trolley Infeed 1.4 Operator Required:two workers for paving the paper,one worker for inspection,and one worker for outfeed Detailed Parts Included: Main Press Machine Hydraulic Station Control Panel Box Infeed Belt Trolley Outfeed Trolley Upper Oil Can
Technical Specifications:
Model	QH214x8/160-1
Nominal Pressure	16000 KN
Unit Pressure	≤53.7kg/cm2
Finished Board Size	1220x2440mm
Thickness Range of the Board	8-45mm
Infeed Direction	Horizontal
Lamination Sides	Double Size
Motor Power	22.75kw
Hot Platen Size	1400*2600mm
Thickness of Upper Platen	140mm
Thickness of Lower Platen	100mm
Temperature of Hot Platen	≤200℃
Weight	41 Tons
Main Cylinder	Ф320mm×8pcs
Stroke of Main Cylinder	200mm
Lifting Cylinder	Ф63mm×4pcs
Hydraulic Pressure	≤25MPa
Hydraulic Oil	46# Fire Resistant Oil,6cansx170 kg/can
